✦ FROM IDEA TO FINAL ELECTRONIC PRODUCT IN YOUR HAND
EMBEDDED SYSTEMS
Complete turnkey hardware solutions: PCB design, PCB manufacturing, firmware development, component sourcing, PCB assembly (PCBA), custom 3D enclosure, packaging, and global shipment.
03
CAN & MODBUS FIELDBUS
LAT: 28.61 // LNG: 77.20
· · · · · · · · · · · · · · · ·
TURNKEY HARDWARE PIPELINE
Fabrication Portfolio
Our Past PCB Designs
A gallery of our in-house engineered boards: multilayer micro-controllers, high-speed differential routing, isolated industrial power stages, and production-ready PCBA designs.
4-LAYER ENIG
pcb1.png / .jpg
STM32 Master Controller
High-density 4-layer board with 50Ω single-ended trace tuning, dedicated ground return planes, and low-noise analog separation.
2-LAYER 2OZ
pcb2.png / .jpg
Isolated Industrial Fieldbus
Galvanically isolated CAN 2.0B / CAN-FD and RS-485 transceiver board engineered for harsh high-EMI automotive and factory floors.
4-LAYER 2OZ
pcb3.png / .jpg
Solar Pv Router
Wide copper pours rated for 40A continuous load with low-inductance ceramic bypass capacitors and thermal vias for direct heat dissipation.
4-LAYER RF
pcb4.png / .jpg
ESP32 Wireless Edge Node
Miniaturized RF board featuring controlled 50Ω coplanar waveguide with ground (CPWG), ceramic capacitors, and low-dropout power regulation.
6-LAYER PRECISION
pcb5.png / .jpg
Esp32 P4 Cosutom Hat
6-Layer board with split ground plane strategy, star grounding, and guarded trace routing to achieve >110dB signal-to-noise ratio.
2-LAYER HEAVY COPPER
pcb6.png / .jpg
High Currunt Mosfet Array
Designed to replace mechanical starters with digital telemetry, current transformer (CT) calibration, and surge suppression MOVs.
8-LAYER MICROVIA
pcb7.png / .jpg
RISC-V High-Speed Carrier
Complex high-density interconnect (HDI) board with length-tuned differential pairs, power integrity decoupling, and blind/buried vias.
4-LAYER LOW POWER
pcb8.png / .jpg
Solar Sensor Node PCBA
Engineered for 5+ years of battery maintenance-free operation using Maximum Power Point Tracking (MPPT) solar harvesting.
Silicon & Protocols
Core Embedded Architectures
Deep hardware mastery across bare-metal microcontrollers, RTOS kernels, high-speed mixed-signal buses, and ruggedized power stages.
Silicon Core
ARM Cortex-M & STM32
Register-level bare-metal development without bloated vendor HALs. Direct register configuration for clock trees (PLL), high-speed timers, and zero-overhead DMA.
- Direct Register & LL (Low-Layer) Drivers
- DMA Transfer Engines for SPI / UART / I²S
- NVIC Microsecond Interrupt Latency
Deterministic OS
RTOS & Kernel Architecture
Preemptive task scheduling and memory-safe thread synchronization. Engineered for deterministic response deadlines under heavy multi-sensor workloads.
- FreeRTOS & Zephyr Kernel Deployments
- Binary Semaphores, Mutexes, & Queues
- Minimal RAM Footprint (< 16 KB)
Industrial Bus
Isolated CAN Bus & Modbus
Robust automotive and factory fieldbus pipelines. Implementing CAN 2.0B / CAN-FD and RS-485 Modbus RTU with galvanic isolation and hardware CRC validation.
- ISO 11898-2 CAN Transceiver Stacks
- RS-485 Modbus Master/Slave State Machines
- TVS Surge & ESD Protection Arrays
Hardware Layout
Controlled Impedance PCB
High-speed multilayer PCB design (4 to 8 layers) with controlled single-ended (50Ω) and differential (90/100Ω) trace geometries, length matching, and solid ground return paths.
- Microstrip & Stripline Impedance Tuning
- Length & Phase Tuning for High-Speed Diff Pairs
- EMI/EMC Compliance & Solid Ground Planes
Power Electronics
Power Stages & Motor Inverters
Heavy-duty power switching circuitry for industrial induction pumps, BLDC motor field-oriented control (FOC), and isolated shunt resistor current feedback.
- MOSFET / IGBT Half-Bridge Gate Drivers
- Low-Inductance DC Bus Capacitor Decoupling
- Active Overcurrent & Thermal Cutoff Logic
Mixed Signal
Sensor Fusion & Analog Frontend
High-resolution analog-to-digital signal conditioning. Low-noise operational amplifiers, 24-bit delta-sigma ADCs, Kalman filtering, and precise I²C/SPI instrumentation.
- Active 2nd-Order Anti-Aliasing Filters
- Isolated Shunt Resistors & Hall Effect Sensors
- Real-Time Recursive Digital Filtering
End-To-End Execution
The Complete Turnkey Lifecycle
From conceptual schematic and component procurement to precision SMT assembly, custom enclosures, and final product boxing in your hand.
01
PCB Design & Schematics
SPICE circuit simulation, component derating, impedance planning, multilayer stackup generation, and DFM validation.
02
Manufacturing & Sourcing
Fabrication of high-density boards, Bill of Materials (BOM) global component sourcing, and authorized distributor verification.
03
PCBA & Firmware Build
Automated pick-and-place SMT assembly, reflow soldering, bare-metal C/C++ firmware flashing, and RTOS driver bring-up.
04
Enclosure & Shipment
Custom 3D CAD snap-fit enclosures, automated HIL testing, protective boxing, and insured door-to-door worldwide shipment.
Engineering Calculators
Embedded & PCB Developer Suite
All 16 in-browser engineering calculators, standard decoders, and real-time waveform visualizers for electronics design.
📐 Trace Width (IPC‑2221)
Calculate required copper trace width, resistance, voltage drop, and power loss.
Required Width—
Resistance—
Voltage Drop—
Power Loss—
⏺ Via Current Capacity
Plated through-hole via current rating, DC resistance, and parasitic inductance.
Max Current—
DC Resistance—
Inductance—
⚡ Clearance & Creepage
High-voltage safety spacing based on IPC-2221B standards.
Min Clearance—
Min Creepage—
〰️ Microstrip Z₀
Characteristic impedance & delay of a surface RF trace over ground plane.
Impedance Z₀—
Effective εᵣ—
Propagation Delay—
▬ Stripline Z₀
Symmetric stripline embedded between dual reference ground planes.
Impedance Z₀—
Signal Delay—
🎨 Resistor Color Bands
Visualizes exact colored bands on a real-time rendered resistor body.
Resistance—
Tolerance—
🔢 SMD Resistor Decoder
Decodes 3-digit, 4-digit, and EIA-96 high-precision SMD package markings.
Decoded Nominal Resistance—
🔋 Capacitor Marking
Decodes standard EIA 3-digit marking code into capacitance & tolerance.
Decoded Capacitance & Tol—
📈 Sallen‑Key Filter Designer
2nd-order active low-pass / high-pass filter with interactive Bode plot.
Resistors R1 / R2—
Capacitors C1 / C2—
💡 LED Resistor Sizing
Calculate ballast resistor with nearest standard E12 series and wattage rating.
Exact R—
Standard E12—
Min Rating (1.5x)—
⏱️ NE555 Timer Engine
Astable / monostable timing calculations with live real-time square wave preview.
Oscillation Freq—
Duty Cycle—
⚙️ Buck/Boost Sizing
Switching converter minimum inductor, ripple peak, and output capacitor.
Min Inductance—
Peak Current—
Min Output Cap—
〰️〰️ Differential Microstrip
Edge-coupled differential impedance (Zdiff) and common-mode (Zcm).
Z_diff—
Z_common—
Effective εᵣ—
⏳ RC Time Constant
Time constant (τ), cut-off frequency, and 10% to 90% rise/fall time.
Time Const τ—
Cutoff f_c—
Rise (10-90%)—
Fall Time—
⚡ Voltage Divider
Loaded output voltage, loop current, and power dissipation per resistor.
Output V_out—
Circuit Current—
Power in R1—
Power in R2—
🔋 Battery Life Estimator
Runtime in hours and days factoring in nominal capacity and circuit efficiency.
Estimated Hours—
Estimated Days—
No engineering calculators match your query.
Direct Comms Link
Initialize Specifications
Connect directly with our embedded engineering team to architect custom silicon, firmware, or hardware blueprints.
